SPECIFICATIONS
Can Be Customized:
| Parameter Name | Specification Value |
|---|---|
| Model Type | Concentric Cable Lapping Machine |
| Motor Power | 1.5KW Industrial AC Motor (IP55 Rated) |
| Tension Control | 0.6KG Electromagnetic Tensioner with Auto-Diameter Tracking |
| Inverter | 3-Phase 380V 1.5KW Variable Frequency Drive (VFD) |
| Web Braking System | 2.5KG Single-Plate Electromagnetic Brake |
| Synchronization | PLC-Controlled Start/Stop/Speed Sync with Host |
| Tape Break Protection | Photoelectric Sensor + PLC Auto-Shutdown |
| Web Length Management | Pre-Set Length + Auto Deceleration at Tape End |
| Lapping Speed | Standard: 1500-1800 RPM Max: 2200 RPM |
| Compatible Tapes | Aluminum Foil, Mylar, Mica (Fireproof), PTFE, Flame-Retardant, Crepe Paper |
APPLICATION & FEATURES
Applications:
High-Voltage Cable Insulation: Precision lapping of mica/fireproof tapes
Shielding Layer Wrapping: Aluminum foil tape for EMI protection
Specialty Cables: PTFE tape for aerospace/medical cables
Fire-Resistant Cables: Mica tape wrapping (IEC 60331 compliant)
Smart Tension Tech
0.6KG electromagnetic tensioner (±0.05N precision)
Auto-adjusts to reel diameter changes
Zero-Downtime Production
Photoelectric sensors + PLC detect breaks in <0.2s
Host-Integrated Sync
PLC interlock with extruders (sync error <0.1%)
High-Yield Mode
2200 RPM (25% faster than industry)
Maintains 99.8% concentricity (IEEE 1212)
Multi-Material Flexibility
Handles 15-200mm tapes (inc. PTFE/crepe paper)
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
