SPECIFICATIONS
Can Be Customized:
| Parameter | Value |
|---|---|
| Model | PT-24-3 |
| Tension Range | 0.5-20N (Adjustable) |
| Control Accuracy | ±0.5% FS |
| Input Signal | 0-10V / 4-20mA |
| Output to Clutch | 0-24V DC, 3A Max |
| Response Time | <10ms |
| Operating Voltage | 24V DC ±10% |
| Operating Temp. | -10°C to +60°C |
| Interface | DIN Rail Mounting |
| Protection Class | IP20 |
APPLICATIONS & FEATURES
Applications:
Wire Stranding Machines
Copper/Aluminum: Ø0.08-3.2mmCable Coiling Systems
Coaxial/Fiber optic windingMagnet Wire Production
Enameling tension control
Features:
Self-Tuning PID - Auto-adapts to load changes
Dual Feedback - Encoder + load cell fusion
Industrial Tough - IP54 / 4kV protection
Zero-Config - Operational in <3 minutes
Global Cert - CE/UL/RoHS compliant
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
